Rose & Krieger

M9 Cylimder

  • Travel to 50mm
  • Integrated Limit Switches
  • Potentiometer Feedback Option
  • Max. Force 300N
  • Max Speed 15mm/s
  • IP 30 Protection
  • Signal Contact Implemented
  • Fail Safe Design (no braked needed)
http://www.iptech1.com/pdf/rka1.pdf

010 Cylimder

  • Travel to 100mm
  • Integrated Limit Switches
  • Potentiometer Feedback Option
  • Max. Force 500N
  • Max Speed 22mm/s
  • IP 54 Protection
  • Signal Contact Implemented
  • Fail Safe Design (no braked needed)
http://www.iptech1.com/pdf/rka1.pdf

015 Cylimder

  • Travel to 600mm
  • Integrated Limit Switches
  • Potentiometer Feedback Option
  • Max. Force 6000N
  • Max Speed 210mm/s
  • IP 66 Protection
  • Signal Contact Implemented
  • Fail Safe Design (no braked needed)
http://www.iptech1.com/pdf/rka2.pdf

LZ 60/80 Cylimder

  • Travel to 1000mm
  • Integrated Limit Switches
  • Potentiometer Feedback Option
  • Max. Force 10000N
  • Max Speed 110mm/s
  • IP 66 Protection
  • Signal Contact Implemented
  • Integrated Controller
  • Synchronous Operation Possible
http://www.iptech1.com/pdf/rka3.pdf

SLZ 90 Cylimder

  • Travel to 2000mm
  • Integrated Limit Switches
  • Potentiometer Feedback Option
  • Max. Force 25000N
  • Max Speed 77mm/s
  • IP 54 Protection
  • Signal Contact Implemented
  • Synchronous Operation Possible
http://www.iptech1.com/pdf/rka4.pdf

Multilift 2-stage

  • Travel to 500mm
  • Integrated Limit Switches
  • Potentiometer Feedback Option
  • Max. Compression Loading 3000N
  • li>Max. Tension Loading 1000N
  • Max Speed 16mm/s
  • IP 20 Protection
  • Optional manual version
  • Synchronous Operation Possible
http://www.iptech1.com/pdf/rka6.pdf

Slimlift 2-stage

  • Travel to 500mm
  • Integrated Limit Switches
  • Potentiometer Feedback Option
  • Max. Compression Loading 4000N
  • li>Max. Tension Loading 2000N
  • Max Speed 32mm/s
  • IP 30 Protection
  • Optional manual version
  • Synchronous Operation Possible
http://www.iptech1.com/pdf/rka7.pdf

Powerlift 2-stage

  • Travel to 650mm
  • Integrated Limit Switches
  • Integrated Control
  • Max. Compression Loading 3000N
  • li>Max. Tension Loading 3000N
  • Max Speed 50mm/s
  • IP 30 Protection
  • Optional manual version
  • Synchronous Operation Possible
http://www.iptech1.com/pdf/rka8.pdf

Alpha Colonne multi-stage

  • Travel to 700mm
  • Integrated Limit Switches
  • Integrated Control
  • Max. Compression Loading 3000N
  • li>Max. Tension Loading 3000N
  • Max Speed 18mm/s
  • IP 30 Protection
  • Optional manual version
  • Synchronous Operation Possible
http://www.iptech1.com/pdf/rka9.pdf

RK FRAMEWORKS

  • The RK FRAMEWORKS® ALUMINUM LUMBER® system includes an Enormous Variety of Extrusion Shapes & Sizes
  • Secure, flush-fitting, positive-grip connectors create optimum conditions for transmitting loads.
  • The exclusive RK dynamic load bolt has a tapered neck which flexes at the beam joints, absorbing vibration, damping resonace caused by dynamic loading
  • RK Hidden Bracket Connectors provide an invisible, right angle connection. RK hidden brackets do not interfere with the installation of accessories
FrameWorks Catalog http://www.iptech1.com/pdf/rk11.pdf

RK CLAMPWORKS

  • The RK CLAMPWORKS® connection system can be configured using an infinite variety of sizes, shapes and clamp fixtures, offering a degree of flexibility that make it beneficial to virtually all industries.
  • RK clamps allow you to make any mechanical structure in the shortest amount of time possible
  • ClampWorks offers cost advatages over traditional connection techniques that require custom fabrication or permanent welding.
  • The RK Rose+Krieger tube clamps are a system of elements especially designed for variable and quick connection of tubes, both round and square of equal or different sizes. The system is comprised of a full range of adjustable clamps. Round and square tubing available in steel, aluminum or stainless steel.
ClampWorks Catalog http://www.iptech1.com/pdf/rk12.pdf

RK STAIRWORKS

  • The RK STAIRWORKS® connection system suitable for many outdoor and indoor applications. From the simplest railings to complicated stairs and working platforms.
  • The easy "socket connection principle" of the internal tension system reduces construction assembly work to a minimum. Without any machine work connection is realized effortlessly by simply tightening a clamping screw.
  • The new quick change system contained in the program extension, additionally increases flexibility and compliments the assembly facility
  • The Profile Assembly System can be used for the substructure of stairs and platforms.
StairWorks Catalog http://www.iptech1.com/pdf/rk13.pdf
From an Applications Engineer
